💡 Importing GDTF Files into Vectorworks 2026: A Step-by-Step Guide
December 10, 2025
The General Device Type Format (GDTF) is revolutionizing the entertainment workflow, connecting design, planning, and control. If you're using Vectorworks 2026.2.1 on Windows 11, importing GDTF files is straightforward. This guide will walk you through the process, from selecting a lighting fixture to applying the GDTF geometry.
1. Select the Fixture in Vectorworks
First, you need to place a lighting device on your drawing.
- Use the Lighting Device Tool to select a fixture.
- Go to "Select Lighting Symbol".
- Find and click on the desired fixture, such as the Robe Lighting Robin Espite.
- Press "Select".
2. Open the GDTF Share Connection
The GDTF files are downloaded from the GDTF Share platform.
- In the Vectorworks menu bar, click "Entertainment".
- Hover over "GDTF".
- Select "Open GDTF Share Connection".
3. Login and Download the GDTF File
Selecting the connection will open a web browser directed to the GDTF Share website.
- Log in to your GDTF Account.
- After logging in, search for and select the fixture you desire.
- Download the GDTF file.
4. Locate the Downloaded GDTF File
Once the GDTF file is downloaded, it will automatically appear in your Vectorworks Resource Manager.
- If the Resource Manager is not visible, press CTRL + R (on Windows) to bring it up.
- The new GDTF file will be available under your Vectorworks Libraries.
5. Insert the GDTF File into the Fixture
Now you need to associate the downloaded GDTF file with the fixture you placed earlier.
- First, select the fixture in your drawing.
- In the Object Info palette, navigate to the "GDTF Fixture" field.
- Click the dropdown menu and choose "Other...".
- This will open the "GDTF Fixture Mode" dialog.
- In the dialog, locate the manufacturer, select the correct mode for the fixture, and click "OK".
6. Apply GDTF Geometry (Optional)
To ensure your fixture's 2D and 3D representations match the GDTF model, you can apply the GDTF geometry.
- With the fixture still selected, check the "Use GDTF Geometry" box in the Object Info palette.
- The 3D and 2D models of the fixture will update accordingly.
Following these steps, you can successfully import GDTF files and enhance your lighting design workflow in Vectorworks 2026.
